Cudy AC1200 Wi-Fi Router, Model: WR1200
Cudy AC1200 Wi-Fi Router, Model: WR1200 - Image 2
Cudy AC1200 Wi-Fi Router, Model: WR1200 - Image 3
,

Cudy AC1200 Wi-Fi Router, Model: WR1200

20 $

Categories: , Tag: Brand:
Model Version WR1200 2.0
CPU CPU Details 580 MHz Single-Core, MIPS24KEC
Memory/Stroage Flash/ROM 8 MB (64 Mbit ) NOR
DDR/RAM 64 MB (512 Mbit) DDR3
Wireless 5 GHz Wi-Fi Speed 867 Mbps
2.4 GHz Wi-Fi Speed 300 Mbps
5 GHz Wi-Fi Streams 2T2R (2×2 MIMO)
2.4 GHz Wi-Fi Streams 2T2R (2×2 MIMO)
Wi-Fi Antennas 4× Fixed
Range Performance Max: 120 m (394 ft)
Indoor WiFi range varies depending on the layout and wall materials. See Wall Performance spec for placement suggestions.
Wall Performance Two wooden walls with thickness < 3.8 cm (1.5”)
One concrete wall with thickness < 20 cm (7”)
Wi-Fi Transmission Power
  • CE:
    <20 dBm (2.4 GHz)
    <23 dBm (5.15 GHz ~ 5.35 GHz)
  • FCC:
    <24 dBm (5.25 GHz ~ 5.35 GHz & 5.47 GHz ~ 5.725 GHz)
    <30 dBm (2.4 GHz & 5.15 GHz ~ 5.25 GHz)
Interfaces 10/100 Mbps RJ45 Ports 5
Ethernet Notes 1× WAN port, the rest are LAN ports
LED
  • Power
  • Internet
  • Speed/Link/ACT of Each Ethernet Port
  • Wi-Fi
Physical Buttons
  • WPS Button
  • Reset Button
Power Input DC Jack
Power Power Methods DC
DC 12V 1A
Power Adapter Input: 100 ~ 240 V, 50/60 Hz AC
Output: 12V 1A DC
Reliability Environment
  • Operating Temperature: 0 ℃ ~ 40 ℃ (32 ℉ ~104 ℉)
  • Storage Temperature: -40 ℃ ~ 70 ℃ (-40 ℉ ~ 158 ℉)
  • Humidity: 10% ~ 90% non-condensing
  • Storage Humidity: 5% ~ 95% non-condensing
Mechanical Installation
  • Desktop
  • Wall-Mounting
Dimension 220×135×30 mm
8.66×5.31×1.18 inches
Package Content
  • Main Product
  • Power Adapter
  • Ethernet Cable
  • Installation Guide
Ordering Informaiton Retail Package Dimension 290×250×64 mm
11.42×9.84×2.52 inches
Units per Carton 16
Carton Dimension 53.8×51.6×31.3 cm

Software Specs

Model Version WR1200 2.0
Wireless Wi-Fi Standards Wi-Fi 5
Max Wi-Fi Modulation 256-QAM
Wi-Fi Efficiency MU-MIMO
Wi-Fi Efficiency Note MU-MIMO available on 5 GHz
Max Capacity 128
Recommended Client Upper Limit 40
Max Wi-Fi Channel Width 80 MHz
Wi-Fi Security WPA-PSK (WPA/WPA2)
Guest Network 2.4 GHz, 5 GHz
WPS true
General Operation Modes
  • Wi-Fi Router
  • Access Point
  • Range Extender
  • WISP
  • Client
WAN Mode
  • DHCP
  • Static IP
  • PPPOE
Network QoS Per-User Rate Limiting
DHCP
  • Address Reservation
  • DHCP Client List
  • Server
IP Versions IPv4/IPv6
IPv6 Protocols
  • Relay
  • Dynamic (SLAAC/DHCPv6)
  • Staic (Fixed IP)
  • Passthrough
  • 464XLAT
  • MAP-E
  • DS-Lite
IPTV/VLAN
  • Bridge
  • Tag VLAN
TTL Customization
  • Extend
  • Spoof
  • Custom
IGMP
  • IGMP Proxy
  • IGMP Snooping
Forwarding
  • Port Forwarding
  • Port Triggering
  • UPnP
  • DMZ
Firewall
  • SPI Firewall
  • DoS Protection
  • Block PING
Application Layer Gateway
  • IPSec Passthrough
  • L2TP Passthrough
  • PPTP Passthrough
  • FTP Passthrough
  • TFTP Passthrough
  • H323 Passthrough
  • SIP Passthrough
  • RTSP Passthrough
Utilities VPN Client
  • Wireguard
  • OpenVPN
  • PPTP
  • L2TP
VPN Performance
  • WireGuard Client (UL/DL): 49 / 43 Mbps
  • WireGuard Server (UL/DL): 43.6 / 48 Mbps
DNS Options
  • Manual DNS
  • Rebind Protection
  • Override Clients’ DNS
Wake on LAN true
Online Detection true
Management All Devices Management
  • Wi-Fi Time Schedule
  • MAC Filter
  • IP/MAC Binding
Per-Devices Management
  • Intenent On/Off
  • VPN On/Off
  • Online Time Schedule
  • Device Rename
Content Management
  • Domain Filter
  • IP Filter
System Local Control Method
  • Config Web Page
  • App Control
Remote Control Method
  • TR069/TR098/TR111/TR181
  • Config Page via HTTP
Firmware Upgrade Local Update
Reliability
  • Timed Reboot
  • Backup and Restore
Diagnostic Tools
  • Diagnosis
  • Ping
  • Traceroute
  • NSLookup
  • System Log
Languages
  • English
  • German
  • Spanish
  • French
  • Hebrew
  • Italian
  • Portuguese
Dashboard Panel Internet Status, Devices Management, WAN Status, LAN Status, WISP Status, Wi-Fi Status, VPN Status, DHCP Server Status, System Version
Charts Internet Speed, WISP Speed, Wi-Fi Speed

  • Cudy AC1200 Wi-Fi Router WR1200

    ● Speedy AC1200 Wi-Fi

    ● 5× 10/100 Mbps Ethernet Ports

    ● 4× 5 dBi High-Gain Antennas

    ● Beamforming, MU-MIMO

    ● SPI Firewall

    ● Guest Network

    ● WireGuard/OpenVPN/PPTP/L2TP VPN Client

    ● Multi-Mode: Router/AP/RE/WISP
